Product Details
- Size: 6045*2645*1950mm
- Place of Origin: China
- Brand Name: CHTC JOVE
- Model Number: JV70
- Weight: 6300.000 kg
| Engine Model | Cummins B3.3 |
| Operation weight | 6300 Kg |
| Standerd bucket capacity | 0.23 m³ |
| Hydraulic Flow Rate | 58×2 L/min |
| Grade Climbing Capacity | 35°(70%) |
| Ground Pressure | 39 Kpa |
| Travelling Speed(high / low) | 4.3/2.2 km/h |
| Slewing Speed | 10 rpm |
| Bucket Digging Force | 41.3 kN |
| Dimension (mm) | |
|---|---|
| Length (transportation) | 6045 |
| Height (transportation) | 2645 |
| Width (transportation) | 1950 |
| Minimum ground clearance | 326 |
| Rear swing radius | 1690 |
| Track ground length | 2015 |
| Track total length | 3118 |
| Track gauge | 1550 |
| Track pad width | 400 |
| Upper width | 1840 |
| Working dimension (mm) | |
| Maximum digging radius | 6160 |
| Maximum digging depth | 3910 |
| Maximum digging height | 5460 |
| Maximum unloading height | 3620 |
| Front minimum swing radius | 2657 |
